Top Hammer Drilling Rig

This is a crawler-type Top Hammer Drilling rig, model PVT-DS7. It is mainly used for rock drilling operations in projects such as mine exploitation, tunnel driving, and water conservancy and hydropower projects. Its crawler chassis endows it with good mobility and terrain adaptability.
Send Inquiry
Product Introduction

Technical Specifications



Impact power(kW)

18/21(optional)

Hole Range(mm)

φ76~102/φ76~115

Drill rod

T38,T45 / T45,T51

Hole depth(mm)

0~6000

Deflection angle

L/R 20°

Air compressors

screw-type

Air compressor flow rate(m3/min)

6

Engine power/speed

127kW/2200rpm

Hydraulic flow rate(L/min)

220×2

Dust collector air volume(m3/min)

24max

Crawling speed(km/h)

2.9/4.3

Gradeability

50%(30°)

L×W×H(mm)

14100×2800×2977

Weight(kg)

21000



Product Advantages


With a maximum hole depth of 6,000 mm, DS7 is for bench drilling, foundation piling, road construction, and small-to-medium quarry operations where quick cycle times and frequent repositioning are key.
The shorter drilling depth allows faster retraction and rod handling, significantly boosting daily production in shallow-blast patterns compared to larger rigs.


DS7 offers dual drill rod configurations:
T38 / T45 for φ76–102 mm holes (lighter, faster drilling)
T45 / T51 for φ76–115 mm holes (higher torque for tougher rock)
This flexibility lets operators choose the optimal rod size based on rock hardness and budget, reducing tooling inventory and operating costs.



Advantages of PVT-DS7 Top Hammer Drilling rig



1. It can completely replace traditional manual blasting drilling, ensuring safe and efficient construction while significantly accelerating project progress.

01



2. The single drilling depth can reach up to 6 meters, with a hole diameter ranging from 64 to 127 millimeters.

02



3. Equipped with a 360° rotating platform and international top-grade hydraulic motors, it operates stably and boasts long-lasting durability.

03



4. It enables real-time monitoring of working pressure and intelligently adjusts parameters to adapt to various rock strata, ensuring optimal drilling performance.

04



5. It supports the installation of a dry dust removal system, catering to the needs of diverse operational environments.

05

image001 -


About Us



2

blasthole drilling rig



Chongqing Bolide Engineering Machinery Co., Ltd. are an integrated machine enterprise that combines design, research and development, manufacturing, and sales. Our products include hydraulic rock drilling rigs, cutting drilling rigs, anchor bolt drilling rigs, and material opening obstacle removal crushers. Our company's products are widely applied in various fields such as highways, railways, airports, water conservancy projects, mines, industrial parks, construction development, and national defense engineering construction.

Our company adheres to the development driven by scientific and technological innovation and owns 59 patents, including 29 invention patents. We have multiple patents in technologies such as new hydraulic systems and fuzzy control systems, electro-hydraulic control technology, optimization of hydraulic buffer mechanisms for striking pistons, shock absorption and noise reduction, dust removal, and high efficiency and energy conservation. Our products feature advanced design concepts in terms of construction efficiency, safety, and prevention of dust pollution during construction operations.



quarry drilling rig



FAQ

Q: How about its cross-country performance and mobility?

A: The track dimensions are 4160mm in length and 2800mm in width. It has a traveling speed of 2.9/4.3 km/h, a gradeability of 50%, a maximum obstacle crossing height of 1.8 meters, and transportation dimensions of 14100×2800×2977 mm.

Q: What improvements have been made in drilling efficiency compared to traditional drilling rigs?

A: The overall efficiency has been significantly enhanced. The proportion of rock drilling time has increased from 40% of that of traditional drilling rigs to 70%, while the mobile positioning time has decreased from 30% to 15%. Additionally, it eliminates the need for rod changing (rod changing time: 0%).

Q: Does it have a dust handling solution?

A: the dust collector has an air suction volume of 24m³/min and is equipped with a dedicated waterproof filter element.

Q: How does the fuel system ensure reliability?

A: The three-stage filtration system significantly reduces fuel-related failures for uncompromised operation.

Q: Does the cab design prioritize operator comfort?

A: The rig features an H-frame cab with suspended seating, engineered with ergonomic principles and integrated safety protection systems for optimal operator comfort and security.
